Gearbox AG Panel Roll Forming Machine | Automatic Roofing Line

The ZTRFM Gearbox AG Panel Roll Forming Machine is a fully automatic production line designed for manufacturing AG metal roofing and wall cladding panels. Unlike conventional roofing machines that mainly rely on chain transmission, this model uses a gearbox-driven forming system to provide smoother power transmission, stable operation and reliable performance during continuous production.

AG Panels are widely used in agricultural buildings, warehouses, workshops, garages, commercial buildings, residential projects and steel structure construction. The machine can be customized according to the customer’s exact AG Panel drawing, raw material and production requirements, making it suitable for both established roofing sheet factories and new metal building material production projects.

Gearbox Transmission System

The gearbox transmission system is one of the main features of this AG Panel production line.

During roll forming, each forming station needs stable and synchronized power to gradually shape the flat steel sheet into the required profile. Gearbox transmission provides direct and reliable driving force to the forming system, helping reduce transmission movement and maintaining stable operation during long production runs.

Compared with a conventional chain-based system, the gearbox structure also reduces dependence on long transmission chains that may require regular tension adjustment after extended operation.

This makes the machine particularly suitable for manufacturers looking for a robust production line for regular batch production.

Automatic AG Panel Production

The complete working process includes:

Uncoiling → Feeding → Guiding → Roll Forming → Length Measuring → Automatic Cutting → Finished Panel Receiving

After the metal coil is placed on the decoiler, the sheet is guided into the main forming machine. Multiple precision roller stations gradually form the required AG Panel ribs.

The PLC system automatically measures the finished sheet length and controls the cutting process according to the production settings entered by the operator.

Once the required length and quantity are set, the machine can continuously complete the main forming and cutting operations with minimal manual intervention..

Precision Roll Forming System

The quality of an AG Panel depends strongly on the design and machining accuracy of the forming rollers.

ZTRFM designs the roller layout according to the customer’s confirmed profile drawing. Instead of forcing the metal sheet into its final shape in one step, the panel is gradually formed through a sequence of roller stations.

This progressive forming method helps distribute material deformation more evenly and improves the consistency of rib height, panel width, side overlap and overall appearance.

The forming rollers can be manufactured from high-grade 45# forged steel with hard chrome surface treatment. The smooth and wear-resistant surface helps improve long-term durability while reducing unnecessary marks on coated roofing materials.

Heavy-Duty Machine Structure

A gearbox-driven production line requires a strong machine structure to support the forming stations and transmission components.

The main frame is designed with industrial production in mind, providing stable support for the shafts, rollers and gearbox units. Good machine rigidity helps maintain roller alignment and reduces unwanted vibration during continuous production.

A stable frame is especially important when producing long roofing sheets because small deviations in the forming section may affect panel straightness and overlap accuracy.

The final machine structure can be designed according to the customer’s AG Panel profile and raw material requirements.

Suitable Roofing Materials

The AG Panel machine can process common materials used in metal roofing production, including:

• PPGI pre-painted galvanized steel

• PPGL pre-painted Galvalume steel

• Galvanized steel

• Galvalume / Aluzinc steel

• Color-coated steel

• Suitable aluminum roofing material

Different raw materials have different strength, coating and forming characteristics. For this reason, customers are recommended to provide their actual material information before machine production.

ZTRFM can then design the rollers and forming system according to the required roofing product.

Feeding and Guiding System

Proper material feeding is essential for maintaining a consistent AG Panel profile.

The guiding system keeps the steel sheet correctly positioned before it enters the first forming station. This helps maintain stable rib locations, effective panel width and side overlap dimensions.

The feeding section can be adjusted according to the required coil width, making operation convenient when preparing the production line.

Automatic PLC Control

The machine is equipped with an automatic PLC control system and touch-screen operating interface.

Operators can input the required panel length, quantity and production batch information from the control panel. During operation, the PLC coordinates the forming machine, length measuring system and automatic cutter.

The control interface can also be customized according to the customer’s language requirements.

Electrical standards and machine voltage can be designed according to the destination country, making the production line easier to integrate into different factories.

Automatic Cutting System

After the AG Panel reaches its final profile, it enters the automatic cutting section.

The cutting system works together with the PLC and length measuring device. Once the preset panel length is reached, the cutter automatically completes the cutting cycle.

The cutting blade is designed according to the finished AG Panel shape to help maintain the profile around the cutting position.

An automatic cutting system allows manufacturers to produce different sheet lengths directly from the control panel without manually measuring every finished panel.

AG Panel Applications

AG Panels are popular because they combine practical structural strength, lightweight construction and easy installation.

Finished panels produced by this machine can be used for:

• Agricultural buildings

• Barns and farm structures

• Warehouses

• Industrial workshops

• Garages

• Steel structure buildings

• Commercial buildings

• Residential roofing

• Exterior wall cladding

• Storage facilities

Manufacturers can produce panels in different colors and lengths simply by changing the raw material coil and production settings.

Customized AG Panel Solutions

AG Panel dimensions can vary between manufacturers and regional markets. Therefore, the machine does not have to be limited to one fixed profile.

Customers can send us their finished panel drawing showing complete dimensions. Our technical team can design the forming roller system according to the required product.

Customization can include the AG Panel profile, material specification, feeding width, gearbox transmission arrangement, cutting system, electrical configuration, decoiler and finished sheet handling system.

Optional Production Equipment

Different auxiliary equipment can be added according to factory production requirements.

Available options can include a hydraulic decoiler, coil loading trolley, automatic feeding system, servo tracking cutter, finished sheet receiving table and automatic stacking system.

Customers can select the required level of automation according to production volume, workshop layout and investment plan.

Factory Testing and Quality Control

Before shipment, the complete production line can be assembled and tested in the factory.

The testing process checks the feeding system, gearbox transmission, roller alignment, profile forming, PLC operation and automatic cutting.

Trial production is carried out to confirm that the finished AG Panel matches the approved profile drawing.

If required, customers can also provide their own raw material for machine testing before delivery.

After-Sales Technical Support

ZTRFM provides technical support covering installation, commissioning, machine operation and maintenance.

Customers can receive operating instructions, electrical documentation and remote technical guidance. Engineer installation and commissioning services can also be arranged according to project requirements.

If you are planning to manufacture AG roofing panels, send us your profile drawing and production requirements. ZTRFM can design a gearbox-driven AG Panel roll forming solution based on your actual product and factory conditions.
