Cable Tray Cover Roll Forming Machine for Efficient Cable Management Production

With the increasing demand for organized cable management systems in construction, power distribution, and industrial projects, manufacturers need reliable equipment to produce high-quality cable tray covers efficiently.

Cangzhou Zhongtuo Roll Forming Machinery provides advanced Cable Tray Cover Roll Forming Machines that integrate material feeding, leveling, punching, roll forming, conveying, and finished product collection into one complete production line.

Our machine is designed for manufacturers who require stable operation, accurate forming, and flexible production for different cable tray cover sizes. By combining mechanical strength with modern automation technology, the production line helps customers improve productivity while maintaining consistent product quality.

Complete Production Process and Machine Structure

The Cable Tray Cover Production Line adopts a continuous forming process to reduce manual operation and improve production efficiency. The complete workflow includes:

Hydraulic Decoiling → Material Leveling → Cutting → Punching → Roll Forming → Conveyor Transfer → Finished Product Collection

The production line uses a 3-ton hydraulic decoiler to provide stable material feeding. The leveling and cutting unit ensures accurate material preparation before forming, while the punching system completes hole processing according to customer requirements.

After preparation, the roll forming section gradually shapes the galvanized steel strip into the required cable tray cover profile. Finally, the conveyor system and run-out table help operators collect finished products smoothly.

This integrated design reduces production steps, improves working efficiency, and provides a more reliable solution for large-scale cable tray cover manufacturing.

High Precision Roll Forming System for Stable Production

The core part of the machine is the roll forming system, which directly affects product accuracy and surface quality. Zhongtuo uses high-quality 45# steel rollers with heat treatment and chrome plating technology to improve hardness, wear resistance, and service life.

The forming section contains 7 roller stations and uses a 70 mm shaft structure to maintain stable operation during continuous production. Meanwhile, the size adjustment design allows manufacturers to change profiles by adjusting the machine frame, making the equipment more flexible for different production requirements.

Because cable tray covers often require precise dimensions and smooth surfaces, the machine controls forming pressure carefully throughout the process. As a result, customers can achieve uniform profiles with fewer production defects.

Technical Parameters of Cable Tray Cover Production Line

Item	Specification
Machine Type	Cable Tray Cover Roll Forming Machine
Suitable Material	Galvanized Steel Coil
Material Thickness	0.8–1.5 mm
Material Width	60–420 mm
Material Yield Strength	≤235 MPa
Production Speed	8–16 m/min
Decoiler Capacity	3 Tons Hydraulic Decoiler
Roll Forming Stations	7 Stations
Roller Material	45# Steel with Heat Treatment & Chrome Plating
Shaft Diameter	70 mm
Main Motor Power	4 KW
Punching System	Hydraulic Punching Device
Punching Capacity	125 Tons
Control System	Delta PLC & Touch Screen
Electrical Components	Schneider Components

The machine supports galvanized steel coils with a thickness range of 0.8–1.5 mm and material widths from 60–420 mm. It can achieve production speeds of 8–16 m/min, which makes it suitable for medium and large-scale cable tray cover production.

Intelligent Control System and Reliable Components

To ensure stable operation, the machine integrates a professional electrical control system. The standard configuration includes Delta PLC, Delta touch screen, Delta inverter, Omron encoder, and Schneider electrical components.

Through the PLC control system, operators can easily adjust production parameters, monitor machine status, and manage the entire forming process. Therefore, the equipment reduces operation difficulty and improves production consistency.

Additionally, the hydraulic punching system uses high-strength Cr12MoV molds with heat treatment, achieving excellent durability for continuous punching operations.

Customized Solutions and Global After-Sales Support

Every cable tray manufacturer may have different requirements regarding product dimensions, punching patterns, and production capacity. Therefore, Zhongtuo provides customized roll forming solutions based on customer drawings and production goals.

Before manufacturing, our engineering team analyzes product designs and confirms technical details. During production, we strictly control machining accuracy and assembly quality. After completion, we provide machine testing, operation guidance, and technical support to help customers start production smoothly.

Moreover, we continue to support customers through remote technical assistance, spare parts supply, and professional service solutions. Our goal is not only to provide a machine but also to help customers achieve long-term stable production.

Why Choose Zhongtuo Cable Tray Cover Roll Forming Machine?

As an experienced roll forming machine manufacturer, Zhongtuo focuses on developing durable and practical forming equipment for global industries.

Our Cable Tray Cover Roll Forming Machine offers:

• Stable continuous production performance
• Accurate profile forming capability
• Customized production solutions
• High-quality mechanical components
• Advanced PLC automation control
• Professional installation and technical support

With strong manufacturing experience and a customer-oriented approach, Zhongtuo helps cable management system manufacturers improve efficiency, reduce production costs, and build competitive advantages in their markets.

Conclusion

The Cable Tray Cover Roll Forming Machine is an ideal solution for producing galvanized steel cable covers with high efficiency and consistent quality. Through optimized mechanical design, reliable automation, and flexible customization options, Zhongtuo provides complete production solutions for customers worldwide.

If you are looking for a professional Cable Tray Cover Production Line Manufacturer, Zhongtuo can provide a customized solution according to your product requirements and production plans.
