ZhongTuo Automatic Gutter Roll Forming Machine for Greenhouse Hydroponic Systems Chain

This machine is designed for the continuous production of metal gutters used in greenhouse cultivation, hydroponic farming, and suspended growing systems. It can process materials such as PPGI, galvanized steel, and aluminum, with a recommended material thickness of approximately 0.6–0.8 mm.

The complete line integrates automatic decoiling, roll forming, length setting, cutting, and PLC control. It can be customized according to the customer’s gutter profile, dimensions, material thickness, and actual application requirements, making it suitable for greenhouse projects, hydroponic growing systems, and continuous production of agricultural metal profiles.

Efficient and Stable Continuous Forming

The standard forming speed is approximately 15–20 m/min, while the actual production speed can be adjusted according to the profile shape, material type, and thickness.

The main machine adopts a heavy-duty 350H steel frame combined with Ø80 mm solid shafts, providing good structural rigidity and stable performance during continuous operation.

The forming rollers are manufactured from 45# steel and treated with hard chrome plating. This helps improve wear resistance, surface hardness, and service life while maintaining stable forming quality over long-term production.

A reliable chain transmission system is used to provide stable power transmission and convenient maintenance for continuous production.

Automatic Cutting and PLC Control

The machine is equipped with an automatic length measuring and cutting system. The cutting blades are made of Cr12MoV, offering good hardness, wear resistance, and long service life.

The PLC control system allows operators to set product length, production quantity, batch information, and related operating parameters according to production requirements.

This reduces repeated manual measurement and helps improve production efficiency and finished product consistency.

The standard control interface is available in English, and multilingual interfaces can also be provided for different markets.

Power and Machine Configuration

The main motor power is approximately 7.5 kW, while the hydraulic system power is approximately 11 kW, providing sufficient power for continuous forming and automatic cutting.

The standard electrical configuration is 380V / 50Hz / 3 Phase, and the voltage can be customized according to the customer’s local industrial power supply.

The overall machine dimensions are approximately 8500 × 1000 × 1200 mm, with a total weight of around 4 tons. Final dimensions and weight may vary depending on the gutter profile and selected machine configuration.

The feeding section can be equipped with an automatic hydraulic decoiler to improve coil loading and continuous feeding efficiency. Additional feeding devices can also be configured according to the customer’s production requirements.

Customizable Gutter Profiles

Different greenhouse and hydroponic projects may require different gutter widths, heights, edge designs, drainage structures, and installation methods.

For this reason, the machine can be customized according to the customer’s actual product requirements.

Customers can provide:

Profile Drawing + Material + Thickness + Required Dimensions

Our technical team will analyze the forming process and determine the roller design, machine structure, cutting method, and PLC control solution.

Before manufacturing begins, the final profile and technical requirements can be confirmed with the customer to ensure that the equipment is better matched to the actual production application.

Quality Control

From machine design to final delivery, key production stages are inspected, including:

• Raw material and key component inspection
• Roller and shaft machining inspection
• Main machine assembly inspection
• PLC and electrical system testing
• No-load running test
• Trial production with actual material
• Finished profile dimension and forming quality inspection

After the machine is completed, trial production can be carried out with specified materials according to customer requirements. Photos and videos can also be provided for confirmation before shipment.

Installation and Operation Training

After delivery, we can provide complete technical support, including online installation guidance, machine commissioning, PLC parameter setting, operator training, and daily maintenance guidance.

For projects requiring on-site technical support, engineers can also be arranged for installation, commissioning, and operator training according to the actual project requirements.

Remote Technical Support

After the machine is put into operation, customers can contact our technical team through photos, videos, or online video communication if they encounter problems with PLC settings, electrical control, forming adjustment, or the cutting system.

Our engineers can assist with fault analysis, parameter checking, mechanical adjustment, and maintenance guidance, helping customers solve operating problems more quickly and reduce unnecessary downtime.

Spare Parts and After-Sales Service

We provide long-term after-sales service and spare parts support.

For wearing parts or components that require replacement after long-term operation, suitable parts can be supplied according to the machine model and original technical documentation.

We also provide remote technical consultation, maintenance guidance, troubleshooting support, and machine upgrade assistance.

Our service covers not only machine manufacturing and delivery, but also the long-term stable operation of the equipment after it enters production.

Customized Solution for Greenhouse and Hydroponic Projects

This Hydroponic Hanging Gutter Roll Forming Machine combines continuous forming, automatic cutting, PLC control, and customized design in one production solution.

It is suitable for modern greenhouse farming, hydroponic agriculture, and related growing systems.

From profile confirmation, machine design, manufacturing, and trial production to installation, commissioning, operator training, and after-sales support, we provide a complete solution for hydroponic gutter production.
