Product Overview

Advanced Multi-Size LGS Framing Machine with Vertex BD Software Integration

The ZTRFM Multi-Sizes-in-One LGS Framing Machine is a world-class production solution for Light Gauge Steel (LGS) construction. Powered by genuine Vertex BD Software, this machine enables the fully automated manufacturing of precision wall panels, trusses, and floor joists for steel villa projects. Its unique capability to adjust profile width (75mm-250mm) automatically makes it the most versatile framing machine in the industry.

Key Features & Intelligent Automation

• Multi-Size Capability (All-in-One): Automatically adjust web and flange sizes to produce different C/U profiles ( 89mm, 140mm, or customizable ranges) without manual roller changes.
• Vertex BD Design Integration: Direct data handoff from Vertex BD BIM software. The machine automatically parses design files to execute precise dimpling, swaging, notching, and service hole punching.
• High-Precision CNC System: Advanced servo-driven feeding and punching systems ensure length accuracy within [Specify Tolerance,  ±0.5mm], crucial for the rapid assembly of LGS house frames.
• Full Suite of Functional Punches: Integrated modules for web holes, dimples, swaging, shear, and inkjet coding for easy identification during villa assembly.
• Industrial Internet of Things (IIoT) Ready: Monitor production status, material usage, and machine health in real-time through a cloud-based interface.

Technical Specifications

Applications in Modern Construction

The Light Gauge Steel Roll Forming Machine is the backbone of the off-site construction industry:

1. Luxury Steel Villas: Producing intricate wall panels, roof trusses, and floor joists with zero-error assembly.
2. Multi-Story Residential: Rapid framing for mid-rise light steel buildings up to 6 stories.
3. Modular & Prefab Housing: Ideal for high-volume production of portable cabins, office pods, and disaster relief housing.
4. Commercial Partitioning: Precision-formed profiles for internal non-load-bearing walls in large-scale commercial centers.

Machine Details

Equipped with high-speed hydraulic punching stations and a heavy-duty frame, the ZTRFM framing system ensures precise cut-outs for service holes, notches, and dimples, significantly reducing on-site construction time.

Why Invest in Our BIM-Integrated LGS System?

We provide more than just hardware; we deliver a complete LGS construction ecosystem. By combining our Multi-Size LGS Machine with the industry-standard Vertex BD software, you can minimize design-to-production errors and significantly reduce labor costs. Our machines are built with aircraft-grade components to ensure [Specify Life 20+ years] of reliable service, supported by our global technical team for software updates and field maintenance.

Service & Support

• Global Installation: Our engineers are available for worldwide factory debugging and operator training.
• Software Training: In-depth training on Vertex BD design software included with every machine purchase.
• Customization: Customized punching gap and hole patterns available upon request.
