Part Name
|
Material
|
|
Outer & Inner Rubber
|
NR、NBR、EPDM
|
|
Casing Ply.
|
Nylon Polyester Fabric
|
|
Strengthen Ring
|
Steel wire ring
|
|
Flange
|
Malleable iron
|
|
Working Pressure
|
1.6MPa (16kg f/cm2)
|
|
Deflection Angle
|
|
(a1+a2)45°
|
||||
|
Burst Pressure
|
4.8MPa (48kg f/cm2)
|
|
Vacuum Degree
|
|
53.3KPa(400mmHg)
|
||||
|
Suitable Temperature ℃
|
-15~115 (-30~250 for special materials)
|
|
|
|
|
||||
|
Suitable Medium
|
Air, Compressed Air, Fresh Water, Sea Water, Oil, Acid, Alkali etc.
|
|
|
|
|
||||
|
Nominal Diameter DN
|
|
Length
|
Axial Displacement (mm)
|
|
Lateral Displacement
mm |
Deflection Angle
a1+a2 |
||
|
mm
|
inch
|
mm
|
|
|
(mm)
|
(a1+a2)°
|
||
|
20
|
¾
|
200
|
5~6
|
22
|
22
|
45°
|
||
|
25
|
1
|
200
|
5~6
|
22
|
22
|
45°
|
||
|
32
|
1¼
|
200
|
5~6
|
22
|
22
|
45°
|
||
|
40
|
1½
|
200
|
5~6
|
22
|
22
|
45°
|
||
|
50
|
2
|
200
|
5~6
|
22
|
22
|
45°
|
||
|
65
|
2½
|
265
|
8~10
|
24
|
24
|
45°
|
||
|
80
|
3
|
285
|
8~10
|
24
|
24
|
45°
|
||
