Instead of treating decoiling, punching, forming and stacking as separate operations, this production line integrates the major processes into one coordinated manufacturing system.
Designed for high-speed production with a main machine speed of approximately 70 meters per minute.
The configured production line is designed for material thickness from 0.4 to 1.4 mm.
Integrated 4-in-1 punching configuration supports efficient processing before roll forming.
PLC-controlled servo adjustment provides a controlled solution for configured profile size adjustment.
Finished profiles can be automatically palletized, reducing manual stacking work.
Integrated high-speed inkjet printing supports production marking and identification.
When production volume increases, every unnecessary stop can affect output.
The configured main machine reaches approximately 70 m/min and uses an arch gear box structure for the high-speed production configuration.
High speed + continuous operation + integrated processing.
The production line is equipped with a 3-ton double-head hydraulic decoiler for coil feeding.
The double-head configuration is designed to make coil changeover more convenient for continuous production.
Integrated punching is an important part of a high-speed stud and track production line. The 4-in-1 configuration is designed according to the project's required punching process.
Separate punching operations can add additional handling and labor. Integrating punching into the production line helps maintain a more continuous manufacturing process.
Profile dimensions may vary according to different construction systems and market requirements. The configured line uses PLC-controlled servo motor adjustment for the specified production setup.
Centralized control of the configured production process.
Controlled size adjustment according to the approved production configuration.
Machine design is based on profile drawings and actual production requirements.
Production does not stop at forming and cutting. Finished profiles also need to be collected, organized and prepared for handling.
This Mexico project is configured with a fully automatic palletizing system to reduce manual stacking operations.
| Item | Specification |
|---|---|
| Machine | High Speed Stud and Track Roll Forming Machine |
| Application | Metal Stud & Track Profiles |
| Project | Mexico |
| Material Thickness | 0.4–1.4 mm |
| Material Yield Strength | 223–413 MPa |
| Production Speed | Approx. 70 m/min |
| Machine Structure | Arch Gear Box Structure |
| Punching System | 4-in-1 Punching |
| Decoiler | 3 Ton Double-Head Hydraulic Decoiler |
| Size Adjustment | PLC-Controlled Servo Motor Adjustment |
| Inkjet Printing | High-Speed Inkjet Printer |
| Palletizing | Fully Automatic Palletizing System |
| Power Supply | 440V / 60Hz / 3 Phase |
| Touch Screen | Delta |
| Inverter | Delta |
| Encoder | Omron |
| Control Language | English / Chinese |
Profile dimensions, forming stations and other project-specific mechanical specifications are subject to the approved CAD drawing and final technical configuration.
This project was configured as a high-speed automatic stud and track production solution, combining high-speed forming with integrated punching, size adjustment, printing and automatic palletizing.
Stud and track profiles are not always the same from one market to another. The machine should be designed around your actual profile drawing and production requirements.
Check the main mechanical components and machine operation.
Check the control system and electrical configuration.
Test production according to the agreed project configuration.
Complete final inspection before shipment.
The configured main machine production speed is approximately 70 meters per minute.
The specified material thickness range is 0.4–1.4 mm.
Yes. The project is configured with a 4-in-1 punching system.
Yes. The machine configuration is based on the customer's profile drawing, material requirements, punching pattern and production target.
Yes. This Mexico project includes a fully automatic palletizing system.
Please send your profile drawing, material thickness, material grade or yield strength, punching requirements, required production speed and local power supply.
Tell us your profile size, material thickness, punching requirements and production target. Our engineers can evaluate the drawing and configure a suitable high-speed production line.
