Cable Ladder Frame Z Profile Rolling Forming Machine ZTRFM-fence+11kw

Name: Cable Ladder Frame Z Profile Rolling Forming Machine ZTRFM-fence+11kw
Brand: ZTRFM
SKU: ZT115911258
Availability: InStock

$25,000.00/ Set

Min. Order:1 Set

You can log in to view more discounted prices.Login Now

Price:

$25,000.00

Quantity:

≥1Set

Order CodeZT115911258

Shipping:

Delivery to:

Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.

Specification:

Model Number:

ZTRFM-fence

Power(W):

11kw

Payment:

Transaction Protection:

Secure payments
Money-back protection
24/7 support
Data privacy

Quantity:

Add to RFQ CartSend Inquiry

Product Details
Reviews(0)

Technical Specifications

Type
roll forming machine
Tile Type
Steel
Use
ROOF
Voltage
380V or as required
Rolling Thickness
customized
Feeding Width
customized

Product Description

Cable ladder frame Z profile rolling forming machine

Cable ladder frame Z profile rolling forming machine is designed to make the ladder frame in batch fully automatically. This cable ladder range is a complete cable support system that is easily assembled on site and it is is specifically designed to carry electrical cables in horizontally mounted, heavy duty industrial and mining applications. Here are some usage cases for your reference:

This type ladder is composed by two parts, the Z frame part and the C connection beam with punching. Here is the drawing profiles for your reference. By this type, the ladder could be any width. And for the Z frame, you can choose to do the punching online or offline.

Cable ladder rolling forming machine
Main motor power	15 kw
Hydraulic motor power	7.5 kw
Voltage	380v 50hz 3 phrase
Control system	PLC
Speed	25m/min
Roller station	12
Shaft diameter	60mm
Shaft material	45# Steel quenched and chromed
Roller material	Cr12 Mov
Transmission	gear and chain
Color	Blue and Yellow

Cable ladder frame Z profile rolling forming machine:

Z frame roll forming parameters for your reference: Main motor power: 18.5kw Drive: Chain Main shaft dia: ￠85mm， material: 45﹟refined forge steel Roller material: GCr15 bearing steel, quenching HRC58-62,surface coated chrome with thickness 0.05mm Roll station: 16 stations with 7 leveling rollers Raw material: Black steel or galvanized steel Thickness of raw material: 2-3 mm Working speed: about 7-15m/min(include cutting time) Coder: OMROM PLC: YASKAWA , made in Japan. 380V 50HZ(Depend on customer) Computer operating panel: touching screen

And for the shearing system: Hydraulic cutting Four sets of the cutting mould to replace for different size Hydraulic power: 5.5KW Hydraulic pressure: 20Mpa Blade material: Cr12mov, quenched 58°-62°

This machine we design is slow speed and more economic. If you want to make more sizes and like more high speed machine, we could make also. There are other types same working principle, we could also make.
