Door Roll Forming Machine System > Production Equipment > Roller Shutter Door Frame Roll Forming Machine

Automatic Roll Up Door Shutter Door Roll Forming Machine Full automatic

General Industry Tech Hebei Developing Co.,Ltd

Automatic Roll Up Door Shutter Door Roll Forming Machine Full automatic

Name: Automatic Roll Up Door Shutter Door Roll Forming Machine Full automatic
Brand: 中拓无界
Availability: InStock

$***/ Set

Min. Order:1 Set

You can log in to view more discounted prices.Login Now

Order CodeZT122404336

Production Capacity15 m/min

Rolling Thickness0.8-1.5mm

Cutting TypeHydraulic cutting

Warranty1 Year

Shipping:

Delivery to:

Shipping fee and delivery date to be negotiated. Chat with supplier now for more details.

Specification:

Operation:

Full automatic

Payment:

Transaction Protection:

Secure payments
Money-back protection
24/7 support
Data privacy

Quantity:

Add to RFQ CartSend Inquiry

Product Details
Reviews(0)

Technical Specifications

Production Capacity
15 m/min
Rolling Thickness
0.8-1.5mm
Cutting Type
Hydraulic cutting
Warranty
1 Year
Operation
Full automatic
Control System
PLC control system
Voltage
380V/50HZ/3HP
Material
PPGI, GI, ALUZINC or other composite materials
Decoiler
5 tons (customizable)
Application
for make shutter door
Key Selling Points
high accuracy
Cutting Type
hydraulic cutting

Roll-Up Door Forming Solution

The ZTRFM ISO CE Certificated Roll Up Door Machine is a full automatic metal shutter door roll forming solution for producing customized roll-up door profiles. Its visible production line combines multiple forming stations, a PLC control cabinet, hydraulic cutting equipment and a heavy-duty decoiler configuration for continuous sheet processing.

Full automatic operation: PLC control supports coordinated forming and cutting control.
Roll-up door application: Designed for metal shutter door and roll-up door profile production.
Hydraulic cutting: The source specification identifies hydraulic cutting as the cutting type.
Flexible configuration: Profiles and roller stations can be customized according to the required door profile.

Technical Specifications

Item	Specification
Product Type	Roll-up Door / Metal Shutter Door Roll Forming Machine
Operation	Full automatic
Production Capacity	15 m/min
Rolling Thickness	0.8–1.5 mm
Material	PPGI, GI, ALUZINC or other composite materials
Decoiler	5 tons, customizable
Control System	PLC control system
Cutting Type	Hydraulic cutting
Voltage	380V / 50HZ / 3HP
Warranty	1 Year
Machine Weight	5500 (unit not specified in source)
Origin	CN; HEB

Machine Structure & Control

The forming section uses a series of visible roller stations to shape the incoming coil into the required roll-up door profile. The PLC cabinet provides the operator interface, while the hydraulic cutting section is positioned for controlled cut-off after forming. Configuration details such as the profile and roller-station arrangement can be adapted to the customer's required product drawing.

Roll forming stations and feed section

PLC control cabinet and hydraulic cutting area

Product Visual

Roll-up door forming machine in a workshop

Applications & Support

Metal shutter door and roll-up door profile production.
PPGI, GI, ALUZINC and other compatible composite coil materials.
Machinery test report and video outgoing-inspection are provided in the source record.
After-sales service includes field maintenance and repair service, with a 1-year warranty stated in the source record.

FAQ

Can the profile be customized?
Yes. The source record identifies the profiles as customized and the roller stations as configurable according to requirements.

What control method is used?
The machine uses a PLC control system with full automatic operation.

What cutting method is specified?
Hydraulic cutting is listed in the product attributes.
