One Machine, Two Profiles. A Space-Saving Roll Forming Solution for Metal Fencing Components.
The ZTRFM 2-in-1 Fence Post Roll Forming Machine is designed for manufacturing metal fencing profiles and fence rail brackets from pre-painted galvanized steel (PPGI), galvanized steel (GI), and other suitable metal coils.
Featuring a dual-profile production concept, the machine can be configured to produce two types of fence rail bracket profiles. The two forming sections can operate independently, allowing operators to select the required production mode according to their needs.
With an integrated feeding system, precision roll forming, automatic punching and servo-controlled flying cutting, this production line helps improve manufacturing efficiency and maintain consistent product quality. Its compact layout also helps save workshop space and simplify daily operation.
Zhongtuo provides customized machine configurations, installation guidance and commissioning support to help customers establish an efficient fence component manufacturing line.
One machine configured for two fence rail bracket profiles. Independent operation helps improve production flexibility and reduce equipment footprint.
The servo tracking flying shear system cuts profiles during continuous production, helping reduce unnecessary line stops when configured for the relevant production mode.
A touchscreen control cabinet supports convenient parameter setting and production management. Siemens or Delta control components are available according to configuration.
Precision-machined rollers and a solid shaft structure support stable forming and consistent profile dimensions.
Optional or configured lubrication systems help protect tooling, reduce friction and simplify routine maintenance.
Roller stations, profile dimensions, punching patterns, electrical specifications and downstream equipment can be customized to suit project requirements.
Reference specifications. Final parameters are subject to the confirmed technical agreement and customized machine configuration.
| Product Name | 2-in-1 Fence Post Roll Forming Machine |
| Forming Material | PPGI, GI and other compatible metal coils |
| Material Thickness | 0.8–1.2 mm, subject to profile and material strength |
| Roller Stations | 14 stations, customizable |
| Shaft Diameter | 70 mm solid shaft |
| Roller Material | Cr12MoV or 45# steel with specified surface treatment; confirm final tooling configuration |
| Machine Frame | Welded steel frame |
| Transmission | Gearbox drive |
| Forming Speed | Up to 40 m/min, depending on profile and configuration |
| Main Motor Power | 7.5 kW |
| Hydraulic Power | 5.5 kW |
| Machine Dimensions | Approx. 7000 × 2000 × 1500 mm; customizable |
| Machine Weight | Approx. 6 tons; subject to final configuration |
| Control System | PLC touchscreen; Siemens or Delta options |
| Electrical Supply | 380 V, 50 Hz, 3-phase; other specifications available on request |
| Decoiler | Manual decoiler included; powered or hydraulic decoiler optional |
| Cutting System | Automatic cutting; servo tracking flying shear configuration |
| Language | Customizable HMI language |
The decoiler supplies coil material to the forming line. Adjustable guide wheels and handwheels help guide and align the strip for smooth feeding.
Precision forming rollers progressively shape the metal strip into the required fence profile. Roller design and tooling are customized according to approved drawings.
Integrated punching and cutting functions produce specified holes and finished lengths. The servo flying shear can support continuous cutting when matched to the production setup.
The touchscreen interface allows operators to configure production parameters and manage machine operation. Electrical components and language can be customized.
The hydraulic system supplies power to compatible punching and cutting units. A cooling fan and temperature monitoring help manage operating conditions.
The receiving table collects finished profiles. An automatic stacking or packing system can be added to improve downstream material handling.
The actual production sequence depends on the selected profile, punching requirements and machine configuration.
The finished profiles can be used in compatible metal fencing systems for residential, commercial, industrial and public infrastructure projects.
Garden fences, boundary fencing and outdoor enclosures.
School grounds, business premises and property boundaries.
Factory perimeters, storage facilities and industrial sites.
Compatible fence posts, rails and rail brackets for metal panel installations.
Every fencing project has different profile dimensions, connection methods and installation requirements. Zhongtuo can customize the roll forming solution according to customer drawings, material specifications and production targets.
Please provide your profile drawings, material thickness, coil width, required production speed and local power supply for a suitable proposal.
It is designed for compatible PPGI and GI coils. Other materials should be confirmed according to their mechanical properties and the approved profile design.
The machine is configured to manufacture two specified fence rail bracket profiles. The forming sections can operate independently according to the confirmed machine design.
Yes. Customized tooling, roller stations, punching positions and cutting lengths can be developed according to customer drawings and technical requirements.
The machine can be configured for the customer's local electrical supply and project requirements. Please confirm the required voltage, frequency, applicable standards and installation conditions before ordering.
Installation guidance and commissioning support can be arranged according to the agreed supply scope and service terms.
