2-in-1 Keel Roll Forming Equipment for Hat Channel and Angle Steel Production High Precision

Hat Channel & Angle Steel Dual Profile Roll Forming Machine：2-in-1 Keel Forming Equipment

Description:The Hat Channel & Angle Steel Dual Profile Roll Forming Machine is a multifunctional 2-in-1 cold roll forming equipment specially developed for light steel keel manufacturing. This integrated machine perfectly combines hat channel forming and angle steel forming functions in one single unit, enabling automatic production of standard hat-shaped furring channels and L-shaped angle steel purlins without replacing equipment. Designed for the construction steel framing industry, it processes galvanized steel, PPGI, aluminum and cold-rolled steel strips into high-precision building keel profiles in one continuous workflow.

Different from traditional single-function roll forming machines that only produce one profile, our dual-purpose forming machine realizes double-profile production on one machine base. It effectively saves factory space, reduces equipment investment costs, and improves production flexibility for metal profile manufacturers. Widely applicable to ceiling furring systems, wall partition framing, building decoration steel structures and municipal support profiles, this dual forming unit has become a cost-effective core equipment for global light steel processing enterprises.

Dual Profile Production Capacity

This 2-in-1 forming machine supports independent and switchable production of two core building profiles, meeting diverse construction steel demands with one device.

Hat Channel Forming Function: The machine produces standard hat shape keels (also known as top hat channels and furring channels) with smooth surface and uniform structural size. Hat channels processed by this equipment feature lightweight, high rigidity and strong bearing capacity, which are widely used for ceiling suspension systems, interior wall cladding supports and drywall framing systems. The adjustable forming structure supports multiple common specifications of hat channels to adapt to different architectural decoration standards.

Angle Steel Forming Function: It can automatically roll and form equal-angle and unequal-angle L-shaped steel profiles. The finished angle steel has precise right-angle bending, neat incision and stable structure, suitable for wall corner protection, building edge trimming, steel structure fixing supports and equipment installation brackets. The whole cold bending process does not damage the metal material texture, ensuring high toughness and compression resistance of the finished angle steel products.



Core Machine Advantages

2-in-1 Integrated Design, Higher Cost Performance

Integrating two independent forming systems on one rigid machine frame, this dual profile machine replaces two separate single-function machines. It greatly reduces equipment purchase cost, saves workshop floor area, and simplifies daily management and maintenance work. For small and medium-sized profile processing factories and decoration material manufacturers, it effectively improves asset utilization and expands product production range without excessive investment.

Fully Automatic Intelligent Operation

Equipped with mature PLC intelligent control system and human-machine touch screen interface, the machine realizes one-key switching between hat channel and angle steel production modes. All production procedures including uncoiling, leveling, rolling forming, hydraulic punching and fixed-length cutting are completed automatically. Operators only need to set parameters such as product width, thickness and cutting length on the screen, and the equipment can run continuously stably, reducing manual operation errors and labor dependence.

High Forming Precision & Stable Quality

The forming rollers are made of high-quality alloy steel with heat treatment and precision grinding technology, featuring high hardness, wear resistance and long service life. The thickened welded machine frame effectively avoids vibration and deformation during long-term high-speed operation. Equipped with servo tracking cutting system and precise positioning device, the dimensional error of finished profiles is controlled within the international standard range, ensuring consistent and standardized product quality for batch production.

Wide Material Compatibility & Strong Adaptability

The machine supports processing of various metal raw materials, including galvanized steel coil, color coated steel coil, cold-rolled steel strip and aluminum strip. It adapts to conventional material thicknesses used in architectural decoration. The flexible parameter adjustment system can meet the production needs of multiple profile specifications, realizing multi-purpose production and improving market competitiveness of manufacturers’ products.

Low Failure Rate & Easy Maintenance

Adopting modular assembly structure and standardized international brand core components, the equipment runs stably with low noise and low failure rate. The optimized transmission structure reduces component wear during operation. The open structural design facilitates daily cleaning, lubrication and parts replacement, greatly reducing later maintenance time and operating costs.



Complete Working Process

The dual profile roll forming machine adopts continuous cold bending molding technology, with a smooth and efficient full-automatic production flow. Firstly, the uncoiling system automatically and stably releases the raw steel strip. Next, the leveling device corrects the unevenness of the raw material to eliminate initial deformation. Then, the steel strip enters the precision rolling forming area, and is gradually bent into standard hat channel or angle steel shape through multi-pass roller extrusion. After that, the hydraulic punching system completes preset hole processing according to construction requirements. Finally, the servo fixed-length cutting system realizes accurate cutting, and the finished products are automatically output, realizing uninterrupted assembly line production.

Main Application Fields

Profiles produced by this dual forming machine are indispensable light steel components in modern construction and decoration industries. Hat channels are mainly used for indoor ceiling keel suspension, partition wall framing, exterior wall cladding support and prefabricated building interior structures. Angle steel profiles are widely applied in building corner reinforcement, decorative edge sealing, steel structure support fixing, municipal engineering facilities and mechanical equipment bracket production. Suitable for commercial buildings, residential decoration, industrial plants, prefab houses and various architectural engineering projects.



Quality Assurance & Global Service

Our dual hat channel and angle steel roll forming machine is manufactured in strict accordance with international mechanical production standards and has passed repeated factory aging tests and precision detection. All equipment meets CE certification standards, supporting safe export and market access in Europe, Southeast Asia, Africa, the Middle East and other global regions.

We provide one-stop overseas service solutions for global customers. Before delivery, we conduct full machine debugging and continuous operation testing, and provide complete English operation manuals, maintenance guides and operation video tutorials. We support personalized customization of machine parameters and profile molds according to customers’ local market standards and production needs. In addition, we offer long-term remote technical guidance, fault diagnosis and spare parts supply services to ensure stable and efficient operation of customer equipment.



Why Choose Our Dual Profile Roll Forming Machine

We are a professional manufacturer focusing on the R&D and production of light steel keel forming equipment, with rich experience in global equipment export. Compared with traditional single-function machines and similar dual-purpose equipment on the market, our hat channel & angle steel dual forming machine has more reasonable structural design, higher production efficiency and more stable performance. Adopting factory direct sales mode, we eliminate intermediate agents’ price difference and provide customers with high-quality equipment at competitive prices.

Whether you need small-scale customized production or large-scale batch processing, our 2-in-1 forming machine can perfectly meet your production demands. We adhere to quality-first and service-oriented philosophy, and have won long-term trust and cooperation from customers in many countries around the world.

If you are looking for a high-efficiency, space-saving and cost-effective dual keel forming machine, welcome to contact us for free quotation, detailed parameter consultation and customized production solutions!
