High Speed Glazed Tile Roll Forming Machine for Roof Sheet High Efficiency

Glazed Tile Roll Forming Machine：High-Speed Roof Tile Making Equipment

Description:Looking for a reliable glazed tile roll forming machine that delivers consistent, high-quality roofing tiles at scale? Our engineered cold roll forming lines transform color-coated steel coils into durable, aesthetically pleasing glazed roof tiles with precision accuracy, minimal waste, and fully automated operation. Designed for roofing contractors, building material manufacturers, and construction businesses across Europe, Southeast Asia, the Middle East, Africa, and the Americas, this machine combines heavy-duty construction with intelligent PLC control to maximize your production output and reduce labor costs.



What Is a Glazed Tile Roll Forming Machine?

A glazed tile roll forming machine is a specialized cold roll forming system that continuously processes metal coils — typically color-coated galvanized steel, aluminum, or prepainted steel — through a series of roller stations to shape the characteristic curved profile of traditional glazed roof tiles. Unlike manual tile pressing or concrete tile production, this machine operates on a fully continuous basis: the coil is fed through uncoiling, guiding, roll forming, hydraulic cutting, and output stacking in a single synchronized line. The result is uniform tiles with crisp profiles, consistent dimensions, and a finish that closely mimics classic ceramic or clay glazed tiles, but with the strength and light weight of steel.

These machines are widely used for residential roofing, commercial building facades, villa construction, industrial workshops, and decorative roofing projects where a traditional tile appearance is desired without the cost and weight of genuine clay tiles.



Core Features That Set Our Machine Apart

Heavy-Duty Roll Forming Structure

The main frame is constructed from thick welded steel sections, stress-relieved to prevent deformation over years of continuous operation. Forming rollers are precision-machined from high-grade 45# steel or forged steel, hardened and polished to ensure smooth material flow and long roller life. Each roller station is carefully calculated and tested to produce the correct tile curvature, rib profile, and edge detail without scratching or damaging the coating surface.

PLC Automatic Control System

Equipped with a user-friendly PLC touchscreen (Siemens or equivalent international brand), the machine allows operators to set tile length, quantity, and production parameters with a few taps. The encoder measures actual material travel in real time, ensuring cut length accuracy within ±1 mm. Changeover between different tile sizes or profiles can be completed in minutes — no manual roller adjustment required for standard size adjustments. This automatic control system significantly reduces operator skill requirements and minimizes setup time between production runs.

Hydraulic Cutting System

The cutting unit uses a hydraulic-powered shear blade that cuts the formed tile cleanly and square without causing deformation or burrs. The hydraulic station features a reliable motor and pump (usually 5.5 kW to 7.5 kW depending on machine capacity), with a built-in cooling system to maintain stable oil temperature during long production shifts. Blades are made from hardened tool steel and can be resharpened multiple times, extending service life and reducing replacement costs.

Gearbox-Driven Main Motor

The forming stations are driven by a heavy-duty gearbox connected to a variable-frequency motor (typically 3 kW to 5.5 kW). The VFD drive allows smooth acceleration and deceleration, protecting the rollers and chain drive from shock loads while maintaining stable line speed. Production speeds range from 8 to 12 meters per minute depending on the tile profile and material thickness, enabling output of thousands of tiles per shift.

Decoiler (Uncoiler) with Coil Car

A hydraulic decoiler supports the raw steel coil and feeds it into the forming line at the correct tension. Most models include a loading car for safe and easy coil positioning — no overhead crane needed for coil loading. The decoiler mandrel expands and contracts hydraulically to securely hold coils of various inner diameters (typically 508 mm or 610 mm).



Production Capacity and Efficiency

Our roof tile making machine is engineered for high-volume, low-maintenance production. A single operator can run the entire line from coil loading to finished tile stacking. Typical output ranges from 1,500 to 3,500 tiles per hour depending on tile length, profile design, and line speed. Compared to manual tile production or imported European equipment, this machine delivers a faster return on investment while maintaining competitive build quality.

Material utilization is optimized through precise cut-length control and minimal scrap. The integrated stacker or exit table neatly collects finished tiles, allowing easy bundling and packaging for storage or transport.



Customization Options for Your Market

Roof tile profiles vary significantly by region. We customize each machine to match the specific tile profiles popular in your market:



Classic glazed tile profiles such as 828, 820, 1000, 1050, and 1200 series — widely used in Asia, Africa, and the Middle East



European-style tile profiles including Roman tile, Bond tile, and double-row tile designs



Material thickness ranging from 0.3 mm to 0.8 mm (color-coated steel)



Working width tailored to your coil size and required coverage width



Color and finish compatibility with PE, SMP, or PVDF coated steel coils



If you already have a tile drawing or sample profile, we can design the roller set specifically for it. This ensures your machine produces tiles that match local building standards and aesthetic preferences exactly.



Quality Assurance and Build Standards

Every machine undergoes full assembly testing in our factory before shipment. We run test coils through the line to verify forming quality, cut accuracy, surface finish, and electrical performance. Key quality points include:



Welded frame stress relief to prevent future twisting or vibration



Hardened and polished roller surfaces for smooth material handling



Premium electrical components from internationally recognized brands



Sealed chain and gearbox housings to prevent dust and oil contamination



Safety guards and emergency stop buttons at all critical access points



Machines are packed in fumigated wooden cases suitable for sea freight, with critical components wrapped in moisture-proof film and secured inside the container to prevent transit damage.



After-Sales Support and Global Service

We understand that buying industrial machinery from overseas requires confidence in after-sales support. Our service package includes:



Detailed English operation manual and maintenance guide



Video installation guidance and on-site commissioning support upon request



Warranty coverage for core components (typically 12 to 24 months)



Long-term supply of spare parts and replacement cutting blades



Remote technical support via email, WhatsApp, or video call



Our engineers have experience installing machines in over 60 countries, and we can provide on-site service at your facility for an additional fee if needed.



Common Applications of Glazed Tile Machines

The glazed roofing tile machine serves a wide range of construction and manufacturing businesses:



Residential house roofing in suburban and rural markets



Commercial building facade and roofing projects



Villa and luxury home construction requiring traditional tile aesthetics



Industrial warehouse and workshop roofing



Building material distributors who supply tiles to local contractors



Custom roofing solution providers for heritage or restoration projects
